What is a Bonding?
Bonding is the intentional connection of metal parts in an electrical system so they share the same electrical potential and provide a low-impedance path for fault current. Bonding connects equipment, enclosures, raceways, and other conductive parts to the grounding system, helping overcurrent devices operate during a fault.
Quick Facts About Bonding
Category
Electrical safety and grounding system
Used for
Connecting conductive equipment and enclosures
Common confusion
Bonding is not the same as grounding
Also called
Electrical bonding, Equipotential bonding
Often discussed with
Electrical Troubleshooting, Electrical Inspection
Key Takeaways About Bonding
- Bonding connects exposed metal parts and stops dangerous voltage differences during normal use or faults.
- A bonding path must stay continuous, sound, and able to carry fault current.
- Bonding differs from grounding. But both functions work together in a safe electrical system.
- Loose, rusty, painted, or missing connections can weaken a bonding path.
- Electricians check bonding with visual inspection, continuity tests, and proper equipment connections.
Understanding Bonding

Bonding is the planned connection of conductive parts in an electrical system. These parts can include metal enclosures, raceways, cable armor, and equipment grounding conductors. They can also include water piping and structural metal that may become energized. These connections keep the parts at nearly the same electrical potential.
Related glossary terms: Electrical Grounding, Grounding Electrode, Continuity Test.
Bonding doesn't normally carry operating current. Its main job appears during a fault. A fault can happen when a damaged conductor touches a metal panel. A sound fault-current path carries current back toward the source. This helps a circuit breaker or fuse open the circuit quickly. Grounding and bonding work together, but they perform different functions.
How Bonding Works, Is Measured, or Is Used?
A bonding connection uses approved conductors, terminals, jumpers, bonding screws, or listed fittings. The connection must remove paint, rust, dirt, or other coatings. This allows metal-to-metal contact when the design requires it.bonding jumper may connect two sections of metal raceway. It may bridge a flexible connection. It may also maintain continuity around equipment that could interrupt the path.
Electricians check bonding through inspection and testing. A continuity test checks for a low-resistance path between connected metal parts. A meter can help find an open connection or unexpected resistance. Test results need context because several factors affect the reading. These factors include lead resistance, parallel paths, equipment design, and the test instrument. The installer also checks conductor size, termination torque, listed fittings, and connection points. These checks must follow the applicable National Electrical Code requirements.
Why Bonding Matters?

Effective bonding reduces the chance that accessible metal stays energized after an insulation failure. It also gives protective devices a stronger path for fault current. This can reduce the time that a fault persists. Without that path, a breaker may not trip as intended. A person touching the equipment could then become part of the fault path.
Bonding also supports reliable operation of electrical equipment. It helps limit voltage differences between connected metal systems. Problems often develop after remodeling, panel replacement, water damage, corrosion, or unapproved wiring changes. A complete inspection looks beyond the panel. It checks raceways, boxes, service equipment, branch circuits, and other conductive parts.
When Bonding Matters Most?
Bonding deserves close attention during a service upgrade, panel change, generator installation, or major rewiring project. It matters when older wiring has been altered. It also matters when metal conduit has been cut. A replacement device might not preserve an existing connection. Service equipment also requires careful separation and connection of grounded and grounding conductors. These connections must follow the system design.
Warning signs include tingling from a metal appliance, repeated breaker trips, visible corrosion, loose wires, damaged raceway, and missing bonding screws. Electrical work without inspection records is another warning sign. Don't rely on a water pipe, gas pipe, or random metal object. These items aren't substitutes for an approved bonding path. In Cincinnati, older homes and buildings may contain several generations of electrical work. Tracing each connection can reveal defects that a simple outlet test misses.
How to Evaluate Bonding?
- Check whether metal enclosures, raceways, and equipment have listed bonding connections.
- Look for loose terminals, corrosion, paint under lugs, damaged fittings, or missing bonding jumpers.
- Confirm that the bonding conductor size matches the circuit, service, or equipment requirements.
- Use a continuity test to identify open paths, then verify results with the system design and code requirements.
- Ask whether recent panel, generator, or remodeling work changed the original bonding arrangement.
Related Concepts Compared
Bonding vs. Electrical Grounding
Grounding connects an electrical system or equipment to earth or a grounding electrode system. Bonding connects conductive parts to create a common path for fault current.
Bonding vs. Grounding Electrode
A grounding electrode is a conductive object, such as a ground rod or concrete-encased electrode, that connects the electrical system to earth. An electrode is one part of a grounding and bonding system, not the complete bonding path.
Bonding vs. Equipment Grounding Conductor
An equipment grounding conductor is a wire that provides a fault-current path from equipment back to the source. Bonding is the broader function that connects equipment and conductive parts, and the conductor is one way to perform it.
Bonding vs. Continuity Test
A continuity test checks whether an electrical path is complete. The test can help verify bonding, but a continuity reading alone does not prove correct conductor sizing, secure terminations, or compliance.
Expert Note
A low-resistance reading does not prove that a bonding system is correct. The connection must also use approved hardware, proper conductor sizing, secure terminations, and a continuous route back to the source. Neutral-to-ground connections must occur only at locations permitted by the system design.
Common Mistakes or Myths About Bonding
- Treating a ground rod as a replacement for an equipment bonding path.
- Leaving paint, rust, or corrosion between a bonding terminal and the metal surface.
- Installing a panel bonding screw in a downstream subpanel where neutral and equipment grounding conductors must remain separated.
- Assuming a lit outlet tester proves that every metal enclosure is bonded correctly.
- Using an unlisted connector or loose metal contact as a permanent bonding connection.
Bonding in Practice: A Real-World Example
An electrician adds a metal junction box to a branch circuit using metal conduit. If a hot conductor touches the box, fault current returns to source and trips the breaker.
